In the demanding world of underground construction and mining, ground support systems face extreme challenges. Moisture, acidic groundwater, and abrasive conditions can quickly degrade traditional steel bolts, leading to safety risks and costly maintenance. SupAnchor, a globally recognized manufacturer of geotechnical reinforcement systems, has answered these challenges with a groundbreaking innovation: the SupFRP® GFRP Friction Bolt. This patented, world-first product represents a leap forward in material science, replacing steel with glass fiber reinforced polymer (GFRP) to deliver unmatched corrosion resistance, safety, and operational efficiency.
Steel friction bolts, while widely used, suffer from two critical drawbacks: susceptibility to rust and the generation of sparks during installation. In environments such as coastal tunnels, chemical plants, or methane-rich mines, these shortcomings can compromise structural integrity and jeopardize worker safety. The SupFRP® GFRP Friction Bolt eliminates both issues entirely. Its non-metallic composition ensures zero corrosion, extending the service life of support structures significantly—even in the harshest chemical surroundings.
Moreover, the absence of sparks during installation makes it ideal for explosive atmospheres, aligning with strict safety regulations in European and American mining operations. As a soil nail system manufacturer and ground anchor bolt factory, SupAnchor understands the critical need for reliable, maintenance-free support, and this bolt sets a new benchmark.
The GFRP material offers a suite of additional benefits:
To quantify the leap in performance, consider the following comparison of key physical and mechanical properties:
| Property | Steel Friction Bolt | GFRP Friction Bolt |
|---|---|---|
| Corrosion Resistance | Low | High |
| Density (g/cm³) | 7.8 | 2.0 |
| Coefficient of Heat Conductivity at 20℃ (w/m) | 64 | 0.75 |
| Electroconductibility | Yes | No |
| Tensile Elongation (GPa) | 200 | 55 |
| Tensile Strength (N/mm²) | 390 | 1000 |
| Working Temperature Range | Below 1000 ℃ | -50 ℃ to 100 ℃ |
The data reveals that while GFRP exhibits a lower tensile elongation, its tensile strength far exceeds that of steel—1000 N/mm² versus 390 N/mm². Moreover, its thermal coefficient is drastically lower, making it thermally stable and non-conductive. These attributes translate directly into longer-lasting, safer ground support.
The first production model, FB-48, is now available with the following technical data:
| Specification | Value |
|---|---|
| Outside Diameter (mm) | 50 |
| Bolt Ultimate Load (kN) | 350 |
| End Load (kN) | 70 |
| Weight (kg/m) | 1.7 |
With a diameter of 50 mm and an ultimate load capacity of 350 kN, the FB-48 delivers robust performance that meets rigorous engineering standards. Its light weight per meter further underscores the handling and logistical advantages on demanding job sites.
The SupFRP® GFRP Friction Bolt is engineered for a broad spectrum of applications where traditional steel falls short. In underground mining, especially in gold, copper, and coal operations, the bolt’s non-sparking nature and corrosion immunity are lifesaving features. It can withstand acidic mine water without deteriorating, reducing the frequency of re-support cycles and lowering total ownership costs.
In rock slope stabilization and tunnel construction, the lightweight design accelerates installation, enabling crews to secure larger areas faster. The electrical insulation property also makes it the preferred choice for metro and rail tunnels, where stray current is a persistent threat to structural steel. As part of a complete hollow bar anchor and self drilling anchor bolt program, contractors can now select the optimal anchoring solution for each ground condition.
With a legacy of innovation, SupAnchor has established itself as a leading self drilling anchor system provider. The company’s extensive R&D investment has yielded a portfolio that includes self drilling anchor bolts, drill-and-grout bolts, and now the GFRP friction bolt—forming a comprehensive geotechnical reinforcement system. All products are manufactured under strict ISO quality certifications, and the company has supplied solutions to landmark infrastructure projects across Europe, Asia, and the Americas.
“Our new GFRP friction bolt reflects our commitment to solving real-world engineering problems with professional, innovative, and collaborative approaches,” said a SupAnchor spokesperson. “By listening to our partners in the field, we continue to push the boundaries of what ground support can achieve.”
As global infrastructure spending grows and safety regulations tighten, the demand for advanced materials like GFRP is accelerating. The SupFRP® bolt not only meets today’s needs but anticipates tomorrow’s challenges, offering a sustainable, cost-effective upgrade over conventional steel systems. Contractors managing high-corrosion environments or seeking compliance with strict safety codes will find in this bolt a ready-made solution.
SupAnchor plans to expand the GFRP product line with additional diameters and load classes, reinforcing its position as a one-stop ground anchor bolt factory for the mining and civil engineering sectors. With this launch, the company reaffirms its role as a technology driver in the global anchorage market.
For more information on SupAnchor’s full range of anchoring systems, including soil nail systems and hollow bar anchors, visit www.supanchor.com.
A European highway project overcame fractured rock and groundwater challenges using SupAnchor's self drilling anchor system. The hollow bar anchors provided rapid installation and high load capacity, showcasing innovation in geotechnical reinforcement.
