In the rugged terrains of European tunneling projects, such as those in the Alps, engineers face complex geological challenges including unstable rock formations and high-pressure groundwater. These conditions demand robust anchoring solutions to ensure safety and efficiency. SupAnchor has stepped up with its SupShell Expansion Rock Bolt System, a self drilling anchor system designed to provide immediate mechanical anchorage and seamless grouting integration. This innovation addresses critical needs in strata control, enabling faster project timelines and enhanced reliability in demanding environments like mining and urban infrastructure development.
The installation process for the SupShell system begins with drilling into the rock or soil, where the self drilling anchor bolt allows for simultaneous drilling and anchoring, reducing labor and time. Key parameters such as outside diameter, length, and weight per meter are tailored to various engineering needs, ensuring optimal performance in diverse conditions. For instance, the system's immediate anchorage capability, supported by expansion shells, prevents delays and improves safety by providing instant grip upon application. This is crucial in projects where ground stability is unpredictable, such as in slope stabilization or tunnel lining.
| Model | Outside Diameter (mm) | Drilling Hole Diameter (mm) | Length (mm) | Weight per Meter (kg/m) |
|---|---|---|---|---|
| R25/EX36 | 36 | Φ40-Φ42 | 132 | 0.62 |
| R28/EX40 | 40 | Φ44-Φ46 | 136 | 0.84 |
| R32/EX44 | 44 | Φ48-Φ50 | 135 | 0.82 |
| R32/EX46 | 46 | Φ50-Φ52 | 176 | 1.2 |
| R32/EX48 | 48 | Φ52-Φ54 | 165 | 1.45 |
These specifications, including the use of CK45 steel and ISO-standard threads, ensure durability and compatibility with international engineering practices. The hollow bar anchor design facilitates efficient grouting, where resin or grout fills the bolt entirely, preventing leakage and enhancing bond strength. This geotechnical reinforcement system not only speeds up advance cycles in tunneling but also reduces overall costs by minimizing rework and improving fortification efficiency.
The SupShell system is versatile, suitable for pre-grouting in soft ground or post-grouting in hard rock, making it ideal for applications in mining, tunneling, and civil engineering projects across Europe and North America. For example, in urban subway expansions, the self drilling anchor bolt enables quick installation without disrupting existing structures, thereby supporting sustainable development goals. Its ability to provide both mechanical and chemical anchorage ensures long-term stability in geotechnical reinforcement, reducing risks in high-stakes environments like dam construction or landslide prevention.
This drill-and-grout bolt technology aligns with global trends toward safer and more efficient infrastructure, contributing to reduced environmental impact and increased project scalability. As industries face tighter regulations and higher safety standards, SupAnchor's solutions offer a reliable path forward, emphasizing innovation and collaboration in geotechnical engineering.
SupAnchor's commitment to R&D and quality is evident in its adherence to EN 10083 and ISO 1461 standards, ensuring that products like the SupShell system meet rigorous performance criteria. With a focus on professional engineering support, the company has deployed its self drilling anchor systems in numerous international projects, from European rail tunnels to American mining operations. This global footprint underscores SupAnchor's role as a trusted partner in geotechnical reinforcement, driving advancements that prioritize safety and efficiency. The brand's innovative approach, combined with collaborative project management, reinforces its message of delivering cutting-edge solutions for complex challenges.
In summary, the SupShell Expansion Rock Bolt System represents a significant leap in geotechnical technology, offering tangible benefits for infrastructure development worldwide. By integrating key features like immediate anchorage and easy grouting, SupAnchor continues to set benchmarks in the industry, fostering a safer and more productive future for engineering projects.
