As global infrastructure projects expand into challenging terrains, from unstable soils to corrosive coastal areas, the demand for efficient and reliable geotechnical solutions has surged. SupAnchor, recognized as Asia's top manufacturer and exporter of self-drilling anchors, addresses these challenges with its T Thread Self-Drilling Hollow Anchor. This product streamlines construction in tunneling, slope stabilization, and foundation engineering, enhancing safety and reducing timelines for European and American projects.
The T thread self-drilling hollow anchor embodies SupAnchor's innovative approach through its "3-in-1 principle," where the hollow steel bar serves as a drilling rod, grout injection tube, and reinforcing element in one operation. This design eliminates the need for separate casing systems, cutting construction time by up to 50% in cohesive or unconsolidated soils. Key features include optimized T threads compatible with standard rotary percussive equipment, a relative rib area (fR) of 0.21 to 0.33 for superior bonding with grout, and 45° angled ribs that minimize splitting forces, keeping crack widths below 0.1 mm under maximum load. To ensure durability, SupAnchor offers three anti-corrosion treatments: hot-dip galvanizing for dry environments, SupCoating (HDG + epoxy) for moderate corrosion resistance, and stainless steel for highly corrosive settings like marine projects.
Here are key specifications for select models, highlighting the versatility of this self drilling anchor system:
| Model | Outside Diameter (mm) | Internal Diameter (mm) | Ultimate Load (kN) | Weight (kg/m) |
|---|---|---|---|---|
| T30/16 | 30 | 16 | ≥220 | 2.70 |
| T30/11 | 30 | 11 | ≥260 | ~3.3 |
| T40/16 | 40 | 16 | ≥660 | 7.17 |
These parameters enable the hollow bar anchor to handle diverse loads, from light-duty slopes to heavy tunnel supports, ensuring adaptability across projects. The standardized T thread design facilitates quick on-site connections with compatible accessories like nuts, couplers, and plates, simplifying logistics and installation.
The T thread self-drilling anchor bolt is widely deployed in critical infrastructure, addressing specific engineering needs. In tunneling, it provides essential support for tunnel faces and surrounding rock, preventing collapses during excavation in variable ground conditions. For slope stabilization, it reinforces natural and man-made slopes, such as highway embankments and mining waste piles, reducing landslide risks. In foundation and retaining structures, it enhances load-bearing capacity in soft soils, supporting buildings and walls. This geotechnical reinforcement system is suitable for both permanent projects, like bridge foundations, and temporary shoring, with anti-corrosion options tailored to environmental demands, from inland dry areas to salt-laden coastal zones.
SupAnchor's focus on research and development, backed by ISO certifications and adherence to the T International Standard, positions it as a leader in the global construction market. The company's innovative self drilling anchor system contributes to safer, more efficient infrastructure in sectors like mining, transportation, and urban development. By fostering collaborative partnerships, SupAnchor drives advancements in drill-and-grout bolt technologies, supporting sustainable growth and resilience in geotechnical projects worldwide. Their extensive model range, including variants like T76 and T103, expands applicability to high-load scenarios, underscoring a commitment to professional, innovative solutions.
