In the demanding world of geotechnical engineering, reliable equipment is paramount. SupAnchor, a leading manufacturer of self drilling anchor systems, has introduced the Sup2000 and Sup5000 grout pumps, designed to meet the rigorous requirements of tunnel construction, mining, slope stabilization, and foundation shoring. These pumps deliver proven performance across diverse geological conditions, ensuring efficient grouting and anchoring operations.
The Sup2000 and Sup5000 grout pumps are engineered for high efficiency and durability. Below are their key technical parameters:
| Parameter | Sup2000 | Sup5000 |
|---|---|---|
| Delivery Rate | 40–2000 L/h | 6000 L/h |
| Delivery Distance | 40–60 m | 80–120 m |
| Delivery Pressure | 4.0 MPa | 6.0 MPa |
| Power Supply | 400V, 50 Hz | |
| Nominal Power | 4.0 KW | 7.5 KW (pump) + 3.0 KW (mixer) |
| Dimensions (L×W×H) | 1350×550×850 mm | 1485×600×850 mm |
| Weight | 230 kg | 375 kg |
These specifications translate into tangible benefits on site. The high delivery pressure (up to 6.0 MPa for Sup5000) enables deep penetration in fractured rock, while extended delivery distances allow operation from safe distances in hazardous areas. The epoxy coating provides exceptional corrosion protection, ensuring longevity even in aggressive chemical environments. Additionally, the pumps are designed for easy dismantling and quick cleaning, reducing downtime between jobs.
The SupAnchor SDA grout pumps are versatile tools suited for a wide range of geotechnical applications:
These pumps are particularly effective when used with SupAnchor's hollow bar anchors, forming a complete geotechnical reinforcement system. The remote control feature enhances operator safety, allowing precise grouting from a distance.
As global infrastructure projects expand into challenging terrains, the demand for reliable ground reinforcement solutions grows. SupAnchor's grout pumps address this need by offering robust performance in tunneling, mining, and slope stabilization. The ability to handle varying grout mixes and deliver consistent output makes these pumps indispensable for contractors seeking efficiency and safety. By integrating these pumps with self drilling anchor bolts and drill-and-grout bolts, engineers can achieve faster installation cycles and improved load transfer.
SupAnchor has established itself as a trusted soil nail system manufacturer and ground anchor bolt factory, with a strong focus on research and development. The company's ISO-certified production processes ensure stringent quality control, and its products have been deployed in numerous international projects. The launch of the Sup2000 and Sup5000 underscores SupAnchor's commitment to innovation and collaboration with global engineering firms. With a philosophy of Professional, Innovative, Collaborative, SupAnchor continues to set benchmarks in geotechnical equipment.
Industry report on SupAnchor's self drilling anchor system used in a complex construction site, highlighting technical parameters, project challenges, and global geotechnical trends.
