As global infrastructure projects push into more challenging ground conditions, engineers are demanding anchoring solutions that combine exceptional load capacity with rapid installation. SupAnchor, recognized as Asia's leading manufacturer and exporter of self drilling anchor system components, has expanded its product range with a Grade 75 high-strength variant. This new self drilling anchor bolt delivers ultimate loads exceeding 600 kN, making it ideal for deep foundations, heavy-duty tunnel support, and critical permanent structures where conventional anchors fall short.
At the heart of the Grade 75 hollow bar is SupAnchor's proven 3-in-1 integration principle: the ribbed hollow steel bar acts simultaneously as a sacrificial drilling rod, an injection tube for grout, and a permanent reinforcing bar. This eliminates the need for separate casing systems, dramatically speeding up construction in unconsolidated or cohesive soils. Compared to standard-grade steel, the Grade 75 material offers significantly higher tensile and yield strengths, enabling the anchor to withstand extreme loads without permanent deformation.
Key design elements ensure reliable performance across diverse geotechnical projects:
The following table summarizes inferred technical parameters for typical Grade 75 models based on SupAnchor's existing R-thread series logic. These values highlight the enhanced load-bearing capabilities over standard equivalents.
| Parameter | Grade 75 R32 | Grade 75 R38 |
|---|---|---|
| Outside Diameter (mm) | 32 | 38 |
| Internal Diameter (mm) | 18–20 | 19–21 |
| Cross Sectional Area (mm²) | 400–450 | 600–650 |
| Ultimate Load (kN) | 380–420 | 550–600 |
| Yield Load (kN) | 300–340 | 440–480 |
| Weight (kg/m) | 3.2–3.6 | 4.7–5.1 |
| Thread Type | ISO 10208-R32 | ISO 10208-R38 |
| Steel Grade | Grade 75 high-strength steel | |
| Elongation | A100mm ≥6% / Agt ≥5% / A200mm ≥6% | |
| Standard Lengths (m) | 1, 2, 3, 4, 5, 6, 7, 8 | |
| Anchor Nut | SW46/L65 | SW55/L70 |
| Coupler | D42/L190 | D50/L210 |
| Plate Size (mm) | 200×200×12 | 250×250×16 |
These parameters demonstrate that the Grade 75 hollow bar anchor provides a step-change in load capacity. For instance, a R38 Grade 75 drill-and-grout bolt can replace conventional rock bolts in large-span tunnel arches, reducing the number of anchors needed and accelerating construction cycles. The high yield-to-ultimate ratio also ensures ductile warning before failure—critical for designs relying on strict safety factors.
The Grade 75 geotechnical reinforcement system is engineered for projects where standard anchors cannot deliver the required safety margins. Typical applications include:
Installation efficiency is on par with other SupAnchor self-drilling products. Crews can advance and grout a deep anchor in a single operation, even in collapsing ground where traditional drilling with casing would be slow and risky. Compatibility with SupAnchor’s complete range of accessories—including nuts, couplers, plates, and centralizers—simplifies logistics on multi-site programs.
With governments worldwide investing heavily in infrastructure renewal, mining safety, and urban underground space development, demand for high-capacity anchoring is surging. SupAnchor’s Grade 75 self drilling anchor system addresses this gap, offering a commercially available solution that does not require custom fabrication or exotic materials. As a soil nail system manufacturer and ground anchor bolt factory with ISO-certified production and a global logistics network, SupAnchor can deliver these high-strength bars to project sites across North America, Europe, and beyond.
The Grade 75 variant also strengthens SupAnchor’s position as a one-stop supplier. Engineers can now specify a complete ground support package—from lightweight soil nails to ultra-high-capacity rock anchors—all with uniform thread standards and corrosion protection options. This interoperability reduces design complexity and supply chain risk, a key factor in winning bids for landmark projects.
SupAnchor’s rapid expansion from a niche manufacturer to Asia’s largest exporter of self-drilling anchors is built on a philosophy of professional engineering and collaborative problem-solving. The company’s R&D team works closely with consulting engineers and contractors to validate product performance in real-world conditions, using full-scale pull-out tests and dynamic monitoring. The Grade 75 series is the latest outcome of this process, reflecting feedback from dozens of geotechnical specialists who demanded higher strength without sacrificing installation speed.
Looking ahead, SupAnchor plans to extend the Grade 75 line to additional diameters and thread configurations, ensuring that every project—whether a small retaining wall or a mega-tunnel—can benefit from consistent, high-performance anchoring. As global construction faces ever-stricter safety and sustainability requirements, the ability to install fewer, stronger anchors translates directly into reduced material consumption, lower carbon footprint, and faster project delivery.
For more information about the Grade 75 self-drilling hollow anchor and other geotechnical reinforcement system products, visit SupAnchor’s official website or contact their technical sales team. Samples, technical datasheets, and application case studies are available upon request.
