As coastal and industrial infrastructure projects face increasingly aggressive environmental conditions, the demand for durable geotechnical reinforcement solutions has surged. SupAnchor, Asia’s leading manufacturer and exporter of self-drilling anchors, has responded with a specialized stainless steel self-drilling hollow anchor designed to resist corrosion while retaining the proven efficiency of its self drilling anchor system. The new variant addresses long-standing challenges in marine engineering, chemical plants, and salt-laden soils, where conventional carbon steel anchors often suffer from rust-induced strength loss and premature failure.
Unlike traditional anchoring methods that require separate casing systems or pre-drilled holes, the stainless steel self-drilling hollow anchor integrates three functions into a single component: sacrificial drilling rod, injection tube, and reinforcing bar. This “3-in-1 principle” enables simultaneous drilling and grouting, which is especially critical in unconsolidated or cohesive soils where borehole collapse is a common risk. By eliminating the need for temporary casing, the system reduces installation time, labor costs, and equipment requirements, making it a preferred choice for contractors facing tight schedules and difficult ground conditions.
The representative model in the stainless steel range, R32SS/15, showcases the mechanical and dimensional characteristics that define the product line. With an outside diameter of 32 mm and a hollow core of 14 mm, the anchor provides a cross-sectional area of 509 mm², delivering an ultimate load of at least 405 kN and a yield load of at least 300 kN. These values are comparable to or higher than standard carbon steel anchors of the same diameter, ensuring that corrosion resistance does not come at the expense of load-bearing capacity. The anchor conforms to ISO 10208 for R32 thread profile and is available in both left-hand and right-hand thread orientations, allowing flexibility in connection configurations.
| Parameter | Value |
|---|---|
| Outside Diameter | 32 mm |
| Internal Diameter | 14 mm |
| Cross Sectional Area | 509 mm² |
| Ultimate Load | ≥405 kN |
| Yield Load | ≥300 kN |
| Weight | 4.00 kg/m |
| Thread Type | ISO 10208 - R32 / Left or Right |
| Steel Type | Stainless steel |
| Elongation | A100mm ≥6% / Agt ≥5% / A200mm ≥6% |
| Length Options | 2 m, 3 m, 4 m, 5 m, 6 m |
| Anchor Nut Size | SW46/L75 |
| Anchor Coupler Size | D42/L220 |
| Anchor Plate Size | 200 x 200 x 12 mm |
Beyond raw strength, the stainless steel hollow bar anchor incorporates an optimized ribbed surface with a relative rib area (fR) between 0.21 and 0.33, enhancing bond with grouting material. The 45° angled rib surfaces are designed to reduce splitting forces on the surrounding soil or rock, maintaining crack widths below 0.1 mm at maximum load. This is particularly important in sensitive ground conditions where excessive deformation could compromise the integrity of adjacent structures. The rib profile, identical to the proven R thread series, ensures full compatibility with standard SupAnchor accessories such as coupling nuts, plates, and centralizers, simplifying logistics and installation.
The inherent corrosion resistance of stainless steel makes this self drilling anchor bolt ideally suited for environments that would rapidly degrade conventional carbon steel. In coastal and marine projects—such as port terminal foundations, sea wall stabilization, offshore wind farm anchors, and coastal tunnel support—the anchor resists saltwater pitting and chloride-induced corrosion, ensuring long-term structural stability. Similarly, in chemical plants and wastewater treatment facilities where industrial vapors and aggressive chemicals are present, the stainless steel material prevents degradation that could lead to sudden failure.
The drill-and-grout bolt is also effective in unconsolidated or cohesive soils where traditional drilling is time-consuming and risky. By drilling and grouting simultaneously, it reduces the chance of borehole collapse and improves installation efficiency. This makes it a valuable component of any geotechnical reinforcement system for both temporary and permanent applications.
Global infrastructure development increasingly demands materials that can withstand extreme conditions over decades of service. The stainless steel hollow bar anchor addresses this need by combining corrosion-resistant metallurgy with the mechanical reliability of a proven anchor system. In tunneling and mining, where ground support must often endure water ingress and aggressive chemistry, this product reduces maintenance frequency and extends service life, lowering total project cost over time. The ability to use the same installation equipment and procedures as standard carbon steel anchors allows contractors to adopt stainless steel options without retraining crews or reconfiguring site logistics.
As a leading soil nail system manufacturer and ground anchor bolt factory, SupAnchor has built its reputation on continuous R&D and adherence to international standards. The company’s self drilling anchor system is certified to ISO 9001 and produces anchors conforming to ISO 10208, EN standards, and other relevant specifications. With projects spanning Asia, Europe, and beyond, SupAnchor’s stainless steel variant reinforces its position as an innovative partner for challenging geotechnical works. The introduction of this product reflects a commitment to providing collaborative, engineering-driven solutions that balance performance, durability, and cost efficiency.
In summary, the stainless steel self-drilling hollow anchor extends the boundaries of what is possible in corrosive ground conditions. By integrating drilling, grouting, and reinforcement into one corrosion-resistant element, it offers a practical, long-lasting solution for infrastructure owners and contractors who cannot accept the risk of anchor degradation. As coastal urbanization and chemical industrial expansion continue, such specialized anchor systems will play an increasingly vital role in ensuring safety and resilience.
