A major infrastructure project in southern Europe has turned to the self drilling anchor system from SupAnchor to secure a 120-meter-long cut slope composed of loose colluvium, weathered schist, and fractured limestone. The slope, located along a strategic highway upgrade linking two regional economic hubs, presented significant geotechnical challenges including shallow groundwater, variable overburden depths, and a history of localized instability during heavy rainfall. Conventional drilled and grouted anchors required cased boreholes and staged grouting, leading to schedule delays and cost overruns. The project team selected SupAnchor's self drilling anchor bolt as a hollow bar anchor solution that drills, installs, and grouts in a single pass, significantly accelerating the construction timeline while improving overall slope stability.
At the construction site, crews equipped with hydraulic drilling rigs install rows of hollow bar anchors on a two-meter grid across the upper and mid-slope benches. Each anchor is advanced through the overburden and into competent bedrock using rotary percussive drilling with simultaneous grout injection. The image above shows workers monitoring the drill mast and grout return, a critical quality control step to ensure full encapsulation of the bar and proper bond development. Behind the active face, completed anchors are being connected to a reinforced concrete facing panel that ties the entire slope into a unified geotechnical reinforcement system.
SupAnchor supplied its R32 and R38 hollow bar anchor series for this project. The hollow bar design features a continuous left-hand thread along the entire length, allowing coupling, drilling, and grouting without the need for a separate casing. This self drilling anchor bolt is manufactured from high-strength steel with a minimum yield strength of 500 MPa and ultimate tensile strength of 650 MPa. The bars are available in standard lengths of 3 m, 4 m, and 6 m, and can be coupled on site to reach anchor depths exceeding 20 m. For this slope stabilization, most anchors were installed at an inclination of 15 to 25 degrees below horizontal, with lengths ranging from 12 m to 18 m depending on the depth to bedrock.
| Parameter | Typical Value |
|---|---|
| Hollow bar diameter | R32 / R38 (32 mm / 38 mm OD) |
| Ultimate tensile load | 280 kN (R32) / 360 kN (R38) |
| Yield load | 230 kN (R32) / 280 kN (R38) |
| Thread type | ISO 10208 left-hand rope thread |
| Corrosion protection | Hot-dip galvanized or epoxy coated (optional double corrosion protection) |
| Standard lengths | 3 m, 4 m, 6 m (coupled on site) |
The selection of R32 and R38 drill-and-grout bolts addressed the site's mixed ground conditions. In the upper weathered zone, the hollow bar's aggressive thread profile provided excellent drilling performance and grout bond, eliminating the need for temporary casing. In the deeper fractured limestone, the bars achieved rapid penetration and allowed pressure grouting to fill voids and fissures, creating a reinforced zone that behaves like a micropile hollow bar anchor network. The hot-dip galvanized coating, applied to the entire bar length, provided the required 100-year service life in this moderately aggressive environment, while the epoxy coating option was reserved for anchors in direct contact with groundwater seeps.
As a leading SDA bolt factory direct supply partner, SupAnchor provided all anchor components including drill bits, coupling nuts, plates, and hex nuts from a single source. This anchor bolt system for geotechnical engineering simplified logistics and ensured component compatibility. The self drilling anchors were delivered to site in 6 m lengths, pre-cut threads protected by plastic caps, and stored on timber supports to prevent coating damage. The project procurement manager highlighted that the ground anchor bolt factory's on-time delivery and dimensional consistency reduced on-site cutting and waste.
The installation followed a controlled drill-and-grout sequence. A pneumatic or hydraulic drill rig with a rotation-percussion head was used to advance the self drilling anchor for retaining walls into the slope. Grout, typically a neat cement mix with a water-cement ratio of 0.4 to 0.5, was pumped through the hollow core under pressure. The grout exits through a port in the drill bit, filling the annular space and creating a strong bond along the entire length of the bar. Drill crews monitored the grout return at the collar to confirm full encapsulation. For anchors in highly fractured zones, a secondary low-pressure grouting stage was performed after initial set to improve bond capacity.
During installation, crews used a grout plant with a colloidal mixer and high-pressure pump. Grout was injected at pressures between 0.5 and 1.0 MPa to ensure adequate penetration. The self drilling anchor for retaining walls provided immediate bond, allowing the construction of a shotcrete facing in lifts. Pull-out tests were performed on 1% of anchors, with acceptance criteria based on EN 1537. The test results validated the design assumptions and were shared with the owner's geotechnical consultant. The successful use of this ground stabilization anchor system also reduced the need for temporary soil nails, saving approximately three weeks on the overall schedule.
Grout mix design was developed based on site water chemistry. A neat cement grout with a water-cement ratio of 0.45 and a superplasticizer dosage of 0.8% by weight of cement was used to achieve a 28-day cube strength of 40 MPa. For anchors intersecting groundwater seeps, a thixotropic additive was introduced to prevent grout washout. Full-scale bond tests confirmed a minimum bond stress of 1.0 MPa in the overburden and 2.5 MPa in bedrock. These values exceeded the design requirements and provided a safety factor greater than 2.0 against pull-out. The project's independent testing laboratory reported no anomalies in grout density or bar installation depth, demonstrating the reliability of the drill-and-grout bolt installation process.
Field pull-out tests conducted on sacrificial anchors confirmed an ultimate bond stress of approximately 1.2 MPa in the weathered schist and more than 2.5 MPa in the limestone, exceeding the design requirement of 0.8 MPa. The self drilling bolt for civil engineering demonstrated consistent load transfer with minimal creep under sustained load. The project's geotechnical engineer noted that the ability to install anchors without casing eliminated the risk of hole collapse in the loose colluvium, a common failure mode with conventional drilling methods in this geology. The hollow bar anchor also allowed immediate tensioning of the anchor head after grout reached initial set, enabling progressive face construction without waiting for full grout cure.
The product image shows the SupAnchor self drilling anchor bolt with its continuous thread and corrosion-resistant coating. The bar's left-hand thread ensures that the coupling and drill bit remain tight during rotational drilling, reducing the risk of decoupling in the hole. This design has been refined through years of ground anchor bolt factory production, with each batch subjected to tensile testing on threaded connections and full-length straightness checks. As a soil nail system manufacturer, SupAnchor also provides matched drill bits, coupling nuts, plates, and nuts to ensure system compatibility and performance.
This slope stabilization project reflects a broader global shift toward faster, safer, and more sustainable geotechnical reinforcement systems. Across Europe and North America, aging transportation corridors, urban expansion into hillside areas, and more frequent extreme weather events are driving demand for robust ground stabilization anchor systems. The self drilling anchor system offers a compelling alternative to conventional anchors, particularly in difficult ground where cased drilling is costly and time-consuming. Industry analysts project steady growth in the use of hollow bar anchors for slope repair, retaining wall construction, and foundation underpinning over the next decade.
Applications for SupAnchor's anchor bolt system for geotechnical engineering extend well beyond slope stabilization. The same self drilling anchor bolt is used as a rock bolt for underground mining, a micropile hollow bar anchor for foundation support, and a self drilling anchor for retaining walls in urban excavations. In tunneling, hollow bar anchors are installed as radial support in the crown and sidewalls, providing immediate ground reinforcement in fractured rock. The drill-and-grout bolt method reduces the number of equipment passes and personnel exposure at the face, improving safety records in complex underground works.
From an economic perspective, the hollow bar method reduces total installed cost when ground conditions are difficult. Contractors avoid the expense of casing, drilling fluids, and multiple grouting stages. The single-pass method also lowers fuel consumption and carbon emissions, aligning with sustainability goals in civil engineering. The self drilling bolt for civil engineering offers a reliable, high-productivity solution for contractors bidding on complex geotechnical packages. Moreover, as a rock bolt for underground mining, the same product family provides consistent performance in high-stress environments, reducing equipment downtime and improving worker safety.
As a global ground anchor bolt factory, SupAnchor maintains ISO 9001:2015, ISO 14001, and ISO 45001 certifications, and its products carry CE marking under the Construction Products Regulation. The company's manufacturing facilities employ automated thread rolling, induction heat treatment, and robotic welding to ensure consistent dimensions and mechanical properties. A dedicated quality laboratory performs tensile, shear, and metallographic tests on every production lot. With SDA bolt factory direct supply capabilities, SupAnchor serves distributors and contractors in over 40 countries, providing technical support from design to installation. As a soil nail system manufacturer, SupAnchor also provides technical documentation and installation training to ensure proper use of its ground stabilization anchor system. Recent projects include highway slope stabilization in Norway, foundation underpinning for a rail viaduct in Germany, and underground mining development in Canada.
The successful performance of SupAnchor's self drilling anchor system on this European highway project underscores the value of a professional, innovative, and collaborative approach to geotechnical engineering. By combining advanced manufacturing, rigorous testing, and field-proven installation methods, SupAnchor continues to deliver ground stabilization anchor system solutions that meet the demanding requirements of modern infrastructure. As the industry moves toward more resilient and cost-effective construction techniques, the self drilling anchor bolt is poised to become a standard tool in the geotechnical engineer's arsenal.
